Two Side Sticker Labeling Machines

Two Side Sticker Labeling Machines
Two Side Sticker Labeling Machines
Product Code : VASAL-150TF
Product Description

Automatic Self Adhesive Two Side Flat Labelling Machine VASAL-150TF

(Photograph is for the reference purpose only. Machine Construction & Specification are subject to change without prior Notice due to Continues up-gradation Process)


Technical Specifications

Model

VASAL-150TF

Direction of Movement

Left to Right

Output/Hour*

3600 to 9000 Nos.

No of Label Applicators

2

Electric Specifications

Conveyor Motor

0.5 HP/ 415 Volts/ 50 Hz

Top Guide Belt Motor

90 Watt, Gear Motor

Sticker Roll Stepper Motors

Stepper 6V / 40 kg x 2

Servo 400 Watt

Delay Device Motors

60 Watt, Gear Motor x 2

Side Belt Device Motors

90 Watt, Gear Motor x 2

Height of Conveyor

860 ± 50 mm


Input Specifications

Label Specification

Length

30 mm to 180 mm

Width

16 mm to 100 mm

Roll Diameter

Max. 300 mm X ID 75 mm

Space between two label

Min. 3 mm in anti clock wise

Container Size

Flat / Square

Length : 15 mm to 100 mm

Width : 10 mm to 50 mm

Height : 58 mm to 240 mm


Utility Requirement

Electric Supply

Single Phase + Neutral + Earthing

Electric Load

2 kW

Air Consumption

2 CFM @ 6 kg for printer or rejection device if such installed


Salient Features

  • Rigid MS structure with elegantly matt finished SS cladding

  • Accurate labeling on parallel flat surfaces

  • Suitable for any type of flat container

  • PLC based operation having security package and counter

  • Product data storage facility

  • Requires no bottle /label change parts

  • Very less down time for change over

  • Suitable for Glass, Pet, HDPE all kind of surfaces

  • Very compact design of applicators made of aluminum

  • Various batch code printers can be installed (optional)

  • Bar code detection, missing label detection & misprinting detection can be installed with rejection (optional)
