Automatic Screw Cap Sealing Machine

Automatic Screw Cap Sealing Machine
Automatic Screw Cap Sealing Machine
Send Inquiry
Product Code : VASCS
Product Description

Automatic Multi Head Screw Cap Sealing Machine VASCS


(Photograph is for the reference purpose only. Machine Construction & Specification are subject to change without prior Notice due to Continues up-gradation Process)


Technical Specifications

Model

VASCM-100

VASCM-150

VASCM-200

No. of sealing head

4 Nos.

6 Nos.

8 Nos.

Output/Hour*

3600 to 6000

3600 to 9000

4000 to 12000

Direction of Movement

Left to Right

Electric Specifications

Main Motor

1.5 HP / 415 Volts / 50 Hz

2 HP / 415 Volts / 50 Hz

Cap Feeding Bowl

300 Watt

Height of Conveyor

860 ± 50 mm

Change parts required

(A) Container: Star Wheel, Back Guide, Feed Worm

(B) Cap : Chuck, Delivery Chute, bowl & Cap Star wheel


Input Specifications

Screw Cap

Diameter

22 mm to 56 mm

Height

15 to 30 mm

Container Size

Round

Ø 22 mm to Ø 100 mm

Respective Height : 40 mm to 240 mm

Flat / Square

Length : 15 mm to 100 mm

Width : 10 mm to 50 mm

Height : 40 mm to 240 mm


Utility Requirement

Electric Supply

3 Phase + Neutral + Earthing

Electric Load

1.5 KW

Air Consumption

0.5 CFM @ 6 kg


Salient Features

  • No container no cap arrangement

  • Rigid MS structure with elegantly matt finished SS cladding

  • Single motor synchronizes conveyor, star wheel & platform turret

  • ACVFD for speed control

  • Adjustable height of conveyor belt to align with other machines of the line

  • Unique Pick & Place type cap transfer arrangement

  • Specially designed heads for adequate torque adjustment

  • Low noise level, low power consumption

  • Universal coupling for quick and easy setting of in feed worm

  • Acrylic enclosure in SS frame (optional)

  • No cap – machine stop arrangement (optional)

  • Motorized height adjustment (optional)
