Automatic Front & Back Sticker Labelling Machine

Automatic Front & Back Sticker Labelling Machine
Automatic Front & Back Sticker Labelling Machine
Product Code : VSAL X-120
Product Description

VSAL-X120 Sticker Labelling Machine (Front & Back Side)


We are manufacturing and exporting of highly efficient Automatic sticker Labeling Machine. Some of the highlighted features of these machines are high speed, accurate labeling and convenient operation. VSAL X120 is used for precise labelling on double sides simultaneously, for containers of any size and shape. The machine operates at the speed of 100 containers per minute, depending upon the label length. Containers of different shapes and sizes can be accommodated on the same machine with or without the need for change parts. The latest SERVO technology makes for precise placement of label and also for high output.


  • Two side applicator Machine.

  • Servo Motor drive

  • Plc Control.

  • HMI Touch screen controls.


Automatic Double Side (front and back side)Sticker Labelling Machine




Upto 5000/Hour

  • Label length

  • Label width

  • Label Placement

160mm maximum

100mm maximum

+/-1 mm (depending on product shape and nature)

Conveyor Height

780mm to 860mm adjustable

Conveyor Length


Conveyor Width


Input Specification

  • Container Dia.

  • Container Height

25 mm. To 80 mm.

200 mm maximum.

Electrical Rating

  • Main Motor

  • Conveyor Drive

  • Pressing Device Drive

Servo Drive Motor

0.25 H.P AC Variable speed motor

0.25 H.P AC Variable speed motor

Power required

440 Volts, 50 Hz  & 220 Volts, 50 Hz.

Dimensions (in mm)

1825 L x 2500 W x 1200 H



Electric Load

2.5 HP


  • Sticker Labeling For Single Side Labeling On Square / Rectangular / Oval / Flat And Such other Shapes Of Containers.

  • One touch automatic label detection and setup.

  • Synchronized label head and conveyor speed.

  • Custom designed for various shapes and sizes of HDPE / PET / Glass / Tin containers for wrap round labelling application.

  • It is widely used in pharmaceutical, chemical, food, cosmetics and other industries round bottle labelling adhesive.

  • No change parts required for various container & label size.

  • GMP conforming design. SS304 construction.

Note: Specifications subject to change due to continuous development.
